3 Way Remote Control HDMI 1.4b Switch enables you to watch multiple devices on one screen; 3 Input; 1 Output
Product Code: PROHDMISW31
- Watch multiple devices on one screen
- DVD, Blu-Ray, monitors, Sky HD, etc.
- Supports resolution 3D/4K*2K
- Easy to use - plug & play
- Comes with remote control
Product Description
3 Way Remote Control HDMI 1.4b Switch enables you to watch multiple devices on one screen; 3 Input; 1 Output
A HDMI Switch is used to switch multiple HDMI Inputs (eg. DVD Player, Set-Top Box, PC, etc) to one output such as a HDTV. Switching is supported by either the push button on the front of the device or by the included remote control.
Features:
- HDMI 1.4 Compatible.
- Full HD 3D Support.
- Full HD 1080p Support.
- x.v.Colour (xvYCC) Support.
- dts-HD Audio Support.
- High Definition Content Protection (HDCP) V1.2.
- Consumer Electronics Control (CEC) Support.
- Resolution up to 1920*1200, including 720i, 720p, 1080i, 1080p.
- Compatible with DVI, using a HDMI to DVI adapter (sold separately).
- Compact design for space saving.
- Metal case for interference shielding.
- Remote control to change input.
- LED indicator to show port in use.
- Automatic switching when a HDMI input is detected.
Technical Information:
Product Code | PROHDMISW31 |
HDMI Source Input Port | 3 |
Display Device Output Port | 1 |
Source Port Connector | 19 pin HDMI |
Display Device Port Connector | 19 pin HDMI |
HDCP Compliant | Yes |
Source Device Selection | Push Button or IR Remote Control |
Input Video Signal | 0.5 - 1.0 Volts P-P |
Input DDC Signal | 5Volts P-P(TTL) |
Deep Color | 12 Bit |
Single Link Range | 1920*1200 |
Bandwidth | Up to 340 Mhz |
Signal Speed | Up to 10.2 Gbps |
The length of input cable | PS3 10m; BLUE DVD 10m |
The length of output cable | 10m |
Vertical Frequency Range | 60 Hz |
Power Consumption (max.) | 1.5 Watts |
Operation Temperature | 0C - 70 C |
Working Voltage | DC 5V |
Power Adaptor | 5V 1A |
Net Weight | 132g |
Dimension: L*W*H (mm) | 100*48*24.5 |
Technical Specification
Product Compliant With IR
No
